Ntn 6200ZNR Deep Groove Ball Bearing - Straight Bore, 10 Mm Id, 30 Mm Od, 9 Mm Width, Single Shielded, With Snap Ring
Product Description
Ntn 6200ZNR Deep Groove Ball Bearing - Straight Bore, 10 mm ID, 30 mm OD, 9 mm Width, Single Shielded, With Snap Ring
Bore Type
Straight
Bore Diameter
10 mm
Outside Diameter
30 mm
Overall Width
9 mm
Closure Type
Single Shielded
Snap Ring Included
With Snap Ring
Bearing Material
High Carbon Chrome Steel
Cage Material
Steel
Cage Type
Pressed
Description
6200ZNR BALL BEARING
Fillet Radius
0.0236 in, 0.600 mm
Harmonization Code
8482.10.5044
Inner Ring Width
0.3543 in, 9.000 mm
Internal Clearance
CN, CN
Manufacturer Upc Number
4547359345254
Max Rpm
30000 rpm
Operating Temperature Range
-40 to 250 ºF
Precision Rating
ISO Class 0
Radial Dynamic Load Capacity
1270 lbf
Radial Static Load Capacity
535 lbf
Weight
0.075 lbs
Bore Diameter
10 mm
Bore Type
Straight
Closure Type
Single Shielded
Outside Diameter
30 mm
Overall Width
9 mm
Snap Ring Included
With Snap Ring
ex-stock subject to prior sales otherwise 6-8 months
US $ 6.58
