Era FS220 20A 2Pole Fireman Switch

Era FS220 20A 2Pole Fireman Switch

Brand:	ERA
Model:	FS220

Product Description

Era FS220 20A 2Pole Fireman Switch

Acting as weatherproof and fire resistance isolator. It is usually connected to active the Shunt Trip Coil connected to MCCB, ACB or other devices to disconnect the power supply to the building or factory in case of fire
Acting as general weatherproof Isolator installed at a location that is conveniet for the fireman to switch off the power supply in the event of fire or emergency.

Technical Data

IEC 60947-3
Rated Voltage 240V/415Va.c 50hz
Utilization Category : AC23A
Die Cast Aluminium Enclosure
Interlocking on OFF Position
Cover can only be opened when switch is OFF
Ingress Protection – IP65 (IEC529)

Connection

Conductors or cable entries from top or bottom
size 2 x M20 from top
max cable size 25sq.mm

RM 146.67

Quantity:

EA

This item is sold by

Shop by Specification Table

You can find items with similar specifications from the table below.

Switch Disconnectors

switch-disconnectors-img

40 A at 415 V AC 50/60 Hz, 41.5 A AC-23 Ue: 400 V, 32 A at 415 V AC 50/60 Hz, 29 A AC-23 Ue: 400 V, 100 A at 415 V AC 50/60 Hz

700 V AC 50/60 Hz, 250 V AC 50/60 Hz, 415 V AC 50/60 Hz, 703 V AC 50/60 Hz, 690 V AC 50/60 Hz

Standards and Certifications

IEC 60947-3 EN 60947-3, EN/IEC 60669-2-4, IEC 60204 IEC 60947-4-1, EN 60947-3 IEC 60947-3, IEC 60947-3

60 mm, 55 mm, 90 mm, 150 mm, 82 mm

73 mm, 106 mm, 131 mm, 152 mm, 70 mm

85 mm, 146 mm, 74 mm, 77 mm, 83 mm

Ip Degree Of Protection

IP4, IP20, IP40, IP65 IP65 conforming to IEC 60529, IP65
